Mark up articles with structured data

最近Wordpressのテーマを久しぶりに書いてみたのですが、Googleウェブマスターツールで構造化データのErrorやWarningが検出されてしまいました。。構造化データについては、scheme.orgのBlogPostingというタイプを利用してMicrodata形式でプロパティ指定を行なっていたのですが、Googleサーチのガイドラインに沿わない部分もあったためかErrorやWarningが報告されていたのかなと思われます（SEOや検索エンジンへの影響については不明です）。

そこで、Googleのドキュメントから現時点でのガイドラインを確認しつつ、いくつかサイトへ組み込みそうなData Typeをピックアップして例としてまとめたいと思います。なお、ご自身のサイトへ適用した際の影響については十分ご確認の上ご自身の責任で判断ください。

Site Structure
1. Your Site Name in Results
  1. 参考資料
2. Breadcrumbs
Creative Works
1. Articles
  1. 参考資料
参考リンク

Site Structure

Your Site Name in Results

Googleの検索結果で表示される名前を指定するために使います。ガイドラインとしてざっくりと以下のようなことが示されています。

指定される名前はサイトドメインをもっともらしく表したものであること
ナチュラルな名前を使うこと。例）×：debug-life.net、○：debuglife
ユニークな名前であること
サイトの説明が不適切であってはならない

Property	Description	Required?
url	サイトの公式なURL	yes
name	サイトの名前	yes
alternateName	サイトの別名	no

スクロールできます

上記をふまえてJSON-LD及びMicrodataフォーマットで書くと以下のようになるでしょうか（例は、WordPressを想定しています）。

JSON-LD
Microdata

{
"@context": "http://schema.org",
"@type": "WebSite",
"name": "DebugLife",
"url": "http://debug-life.net/"
}

{

"@context": "http://schema.org",

"@type": "WebSite",

"name": "DebugLife",

"url": "http://debug-life.net/"

}

WordPress Sample of JSON-LD

add_action('wp_footer', function() {
if (is_home() && is_front_page()) {
$json_ld = json_encode(array(
"@context" => "http://schema.org",
"@type"    => "WebSite",
"name"     => get_bloginfo('name', 'display'),
//"alternateName" => get_bloginfo('name', 'display'),
"url"      => get_bloginfo('url', 'display')
));
echo sprintf('<script type="application/ld+json">%s</script>', $json_ld);
}
});

add_action('wp_footer', function() {

if (is_home() && is_front_page()) {

$json_ld = json_encode(array(

"@context" => "http://schema.org",

"@type" => "WebSite",

"name" => get_bloginfo('name', 'display'),

//"alternateName" => get_bloginfo('name', 'display'),

"url" => get_bloginfo('url', 'display')

));

echo sprintf('<script type="application/ld+json">%s</script>', $json_ld);

}

});

<head itemscope itemtype="http://schema.org/WebSite">
<title itemprop='name'>DebugLife</title>
<link rel="canonical" href="http://debug-life.net/" itemprop="url">

<title itemprop='name'>DebugLife</title>

WordPress Sample of Microdata

add_action('wp_head', function() {
if (is_home() && is_front_page()) {
echo sprintf(<<<EOS
<head itemscope itemtype="http://schema.org/WebSite">
<title itemprop='name'>%s</title>
<link rel="canonical" href="%s" itemprop="url">
EOS
, esc_html(get_bloginfo('name', 'display')), esc_url(get_bloginfo('url', 'display')));
} else if (is_singular()) {
echo sprintf(<<<EOS
<title>%s</title>
<link rel="canonical" href="%s">
EOS
, esc_html(get_bloginfo('name', 'display')), esc_url(get_permalink()));
} else {
echo sprintf(<<<EOS
<title>%s</title>
EOS
, esc_html(get_bloginfo('name', 'display')));
}
});

add_action('wp_head', function() {

if (is_home() && is_front_page()) {

echo sprintf(<<<EOS

EOS

, esc_html(get_bloginfo('name', 'display')), esc_url(get_bloginfo('url', 'display')));

} else if (is_singular()) {

echo sprintf(<<<EOS

EOS

, esc_html(get_bloginfo('name', 'display')), esc_url(get_permalink()));

} else {

echo sprintf(<<<EOS

EOS

, esc_html(get_bloginfo('name', 'display')));

}

});

参考資料

https://developers.google.com/search/docs/data-types/sitename

Breadcrumbs

Webページの階層を示すのに使います。いわゆるパンくずリストです。image属性が必須となっており悩んでしまいます。カテゴリ用の画像やiconを準備しておく必要があるのかもしれません。

Property	Description	Required?
image	階層ページの画像URL	yes
item	ページのID	yes
name	ユーザーに表示されるページの名前	yes
position	ページの階層位置。１から数える	yes

スクロールできます

JSON-LD
Microdata

{
"@context": "http://schema.org",
"@type": "BreadcrumbList",
"itemListElement": [{
"@type": "ListItem",
"position": 1,
"item": {
"@id": "http://debug-life.net/",
"name": "Home",
"image": "http://debug-life.net/logo.png"
}
},{
"@type": "ListItem",
"position": 2,
"item": {
"@id": "http://debug-life.net/entry/category/html",
"name": "Html",
"image": "http://debug-life.net/html-icon.png"
}
}]
}

{

"@context": "http://schema.org",

"@type": "BreadcrumbList",

"itemListElement": [{

"@type": "ListItem",

"position": 1,

"item": {

"@id": "http://debug-life.net/",

"name": "Home",

"image": "http://debug-life.net/logo.png"

}

},{

"@type": "ListItem",

"position": 2,

"item": {

"@id": "http://debug-life.net/entry/category/html",

"name": "Html",

"image": "http://debug-life.net/html-icon.png"

}

}]

}

WordPress Sample of JSON-LD

function get_category_tree()
{
$categories = array();
$cats = get_the_category();
while ($cat = array_shift($cats)) {
$categories[$cat->cat_ID] = $cat;
while ($cat && ($parent = $cat->parent) != 0) {
if ($cat = get_category($parent)) {
$categories[$cat->cat_ID] = $cat;
}
}
}
ksort($categories);
return $categories;
}
add_action('wp_footer', function() {
$items = array();
$jdon_ld = array(
"@context" => "http://schema.org",
"@type"    => "BreadcrumbList",
);
$pos = 1;
$items[] = array(
"@type" => "ListItem",
"position" => $pos++,
"item" => array(
"@id"   => get_bloginfo('url', 'display'),
"name"  => get_bloginfo('name', 'display'),
"image" => 'http://debug-life.net/logo.png'
)
);
if (empty($categories = get_category_tree())) {
goto ECHO_JSON_LD;
}
$keys = array_keys($categories);
for ($i = 0, $size = count($keys); $i < $size; $i++, $pos = $pos + $i) {
$cat = $categories[$keys[$i]];
$images = get_posts(array('post_type' => 'attachment', 'post_status' => 'published', 'posts_per_page' => 1, 'attachement' => $cat->name));
$image = current($images);
$items[] = array(
"@type" => "ListItem",
"position" => $pos,
"item" => array(
"@id"   => get_category_link($cat),
"name"  => $cat->name,
"image" => $image->guid
),
);
}
ECHO_JSON_LD:
echo sprintf('<script type="application/ld+json">%s</script>', json_encode(array(
"@context" => "http://schema.org",
"@type"    => "BreadcrumbList",
"itemListElement" => $items
)));
});

function get_category_tree()

{

$categories = array();

$cats = get_the_category();

while ($cat = array_shift($cats)) {

$categories[$cat->cat_ID] = $cat;

while ($cat && ($parent = $cat->parent) != 0) {

if ($cat = get_category($parent)) {

$categories[$cat->cat_ID] = $cat;

}

ksort($categories);

return $categories;

}

add_action('wp_footer', function() {

$items = array();

$jdon_ld = array(

"@context" => "http://schema.org",

"@type" => "BreadcrumbList",

);

$pos = 1;

$items[] = array(

"@type" => "ListItem",

"position" => $pos++,

"item" => array(

"@id" => get_bloginfo('url', 'display'),

"name" => get_bloginfo('name', 'display'),

"image" => 'http://debug-life.net/logo.png'

)

);

if (empty($categories = get_category_tree())) {

goto ECHO_JSON_LD;

}

$keys = array_keys($categories);

for ($i = 0, $size = count($keys); $i < $size; $i++, $pos = $pos + $i) {

$cat = $categories[$keys[$i]];

$images = get_posts(array('post_type' => 'attachment', 'post_status' => 'published', 'posts_per_page' => 1, 'attachement' => $cat->name));

$image = current($images);

$items[] = array(

"@type" => "ListItem",

"position" => $pos,

"item" => array(

"@id" => get_category_link($cat),

"name" => $cat->name,

"image" => $image->guid

);

}

ECHO_JSON_LD:

echo sprintf('<script type="application/ld+json">%s</script>', json_encode(array(

"@context" => "http://schema.org",

"@type" => "BreadcrumbList",

"itemListElement" => $items

)));

});

<ol>
<li itemprop="itemListElement" itemscope itemtype="http://schema.org/ListItem">
<a itemscope itemtype="http://schema.org/Thing" itemprop="item" href="http://debug-life.net">
<span itemprop="name">Home</span>
<img itemprop="image" src="http://debug-life.net/logo.png" alt="Home"/></a>
<meta itemprop="position" content="1" />
</li>
›
<li itemprop="itemListElement" itemscope itemtype="http://schema.org/ListItem">
<a itemscope itemtype="http://schema.org/Thing" itemprop="item" href="http://debug-life.net/entry/category/html">
<span itemprop="name">html</span>
<img itemprop="image" src="http://debug-life.net/wp-content/uploads/2016/05/debuglife-3.png" alt="html"/></a>
<meta itemprop="position" content="2" />
</li>
</ol>

<ol>

</li>

›

</li>

</ol>

WordPress Sample of Microdata

<?php
function get_category_tree()
{
$categories = array();
$cats = get_the_category();
while ($cat = array_shift($cats)) {
$categories[$cat->cat_ID] = $cat;
while ($cat && ($parent = $cat->parent) != 0) {
if ($cat = get_category($parent)) {
$categories[$cat->cat_ID] = $cat;
}
}
}
ksort($categories);
return $categories;
}
?>
<ol>
<li itemprop="itemListElement" itemscope itemtype="http://schema.org/ListItem">
<a itemscope itemtype="http://schema.org/Thing" itemprop="item" href="<?php bloginfo('url') ?>">
<span itemprop="name">Home</span>
<img itemprop="image" src="<?php bloginfo('url') ?>/logo.png" alt="Home"/></a>
<meta itemprop="position" content="1" />
</li>
<?php if (!empty($categories = get_category_tree())): ?>
<?php $pos = 1;
foreach ($categories as $cat_id => $cat):
$pos++;
$images = get_posts(array('post_type' => 'attachment', 'post_status' => 'published', 'posts_per_page' => 1, 'attachement' => $cat->name));
$image = current($images);
?>
›
<li itemprop="itemListElement" itemscope itemtype="http://schema.org/ListItem">
<a itemscope itemtype="http://schema.org/Thing" itemprop="item" href="<?php echo get_category_link($cat) ?>">
<span itemprop="name"><?php echo esc_html($cat->name) ?></span>
<img itemprop="image" src="<?php echo esc_url($image->guid) ?>" alt="<?php echo esc_attr($cat->name) ?>"/></a>
<meta itemprop="position" content="<?php echo $pos ?>" />
</li>
<?php endforeach ?>
<?php endif ?>
</ol>

<?php

function get_category_tree()

{

$categories = array();

$cats = get_the_category();

while ($cat = array_shift($cats)) {

$categories[$cat->cat_ID] = $cat;

while ($cat && ($parent = $cat->parent) != 0) {

if ($cat = get_category($parent)) {

$categories[$cat->cat_ID] = $cat;

}

ksort($categories);

return $categories;

}

<ol>

</li>

<?php if (!empty($categories = get_category_tree())): ?>

<?php $pos = 1;

foreach ($categories as $cat_id => $cat):

$pos++;

$images = get_posts(array('post_type' => 'attachment', 'post_status' => 'published', 'posts_per_page' => 1, 'attachement' => $cat->name));

$image = current($images);

›

</li>

<?php endforeach ?>

<?php endif ?>

</ol>

Creative Works

Articles

記事のマークアップを構造化するのに使われます。これが結構必須項目が多くて大変です。

Property	Description	Required?
mainEntityOfPage	記事のcanonical URL	recommended
headline	タイトル、110文字以内	yes
image	記事の画像	yes
image.url	画像URL	yes
image.width	画像幅 px	yes
image.height	画像高さ px	yes
publisher	記事の公開者（組織）	yes
publisher.name	公開者名	yes
publisher.logo	ロゴ（※ 縦横比に注意、width <= 600pxでheight 60px）	yes
publisher.logo.url	ロゴのURL	yes
publisher.logo.width	ロゴの幅 px ( 600px以内 ※)	yes
publisher.logo.height	ロゴの高さ px ( 60px以内 ※)	yes
datePublished	記事の公開日 ISO8601	yes
dateModified	記事の最終更新日 ISO8601	recommended
author	記事の著者	yes
author.name	著者の名前	yes
description	記事の説明	recommended

スクロールできます

JSON-LD
Microdata

{
"@context": "http://debug-life.net",
"@type": "NewsArticle",
"mainEntityOfPage": {
"@type": "WebPage",
"@id": "http://debug-life.net/entry/379"
},
"headline": "Mark up articles with structured data",
"image": {
"@type": "ImageObject",
"url": "http://debug-life.net/thumbnail/picture.png",
"width": 700,
"height": 400
},
"datePublished": "2016-06-08T08:00:00+09:00",
"dateModified": "2016-06-08T13:39:00+09:00",
"author": {
"@type": "Person",
"name": "debuglife"
},
"publisher": {
"@type": "Organization",
"name": "DebugLife",
"logo": {
"@type": "ImageObject",
"url": "http://debug-life.net/wp-content/uploads/2016/06/picture.png",
"width": 600,
"height": 60
}
},
"description": "HTMLの構造化について"
}

{

"@context": "http://debug-life.net",

"@type": "NewsArticle",

"mainEntityOfPage": {

"@type": "WebPage",

"@id": "http://debug-life.net/entry/379"

"headline": "Mark up articles with structured data",

"image": {

"@type": "ImageObject",

"url": "http://debug-life.net/thumbnail/picture.png",

"width": 700,

"height": 400

"datePublished": "2016-06-08T08:00:00+09:00",

"dateModified": "2016-06-08T13:39:00+09:00",

"author": {

"@type": "Person",

"name": "debuglife"

"publisher": {

"@type": "Organization",

"name": "DebugLife",

"logo": {

"@type": "ImageObject",

"url": "http://debug-life.net/wp-content/uploads/2016/06/picture.png",

"width": 600,

"height": 60

}

"description": "HTMLの構造化について"

}

WordPress Sample of JSON-LD

global $post;
$thumbnail = get_post_thumbnail_id($post);
$image = array(get_template_directory_uri() . '/img/no-image.png', 600, 270);
if (!empty($thumbnail)) {
if ($image_src = wp_get_attachment_image_src($thumbnail, 'full')) {
$image = $image_src;
}
}
$logo = array("http://debug-life.net/logo.png", 600, 60);
echo json_encode(array(
'@context' => 'http://schema.org',
'@type'    => 'NewsArticle',
'mainEntityOfPage' => array(
'@type' => 'WebPage',
'@id'   => get_the_permalink($post),
),
'headline' => get_the_title($post),
'image' => array(
'@type'  => 'ImageObject',
'url'    => $image[0],
'width'  => $image[1],
'height' => $image[2],
),
'datePublished' => get_the_date(DATE_ISO8601, $post),
'dateModified'  => get_post_modified_time(DATE_ISO8601, $post),
'author' => array(
'type' => 'Person',
'name' => get_the_author_meta('nickname', $post->post_author),
),
'publisher' => array(
'@type' => 'Organization',
'name'  => get_bloginfo('name', 'display'),
'logo' => array(
'@type'  =>  'ImageObject',
'url'    =>  $logo[0],
'width'  =>  $logo[1],
'height' =>  $logo[2],
)
),
'description' => ($post->post_excerpt && strlen($post->post_excerpt) > 0) ?
get_the_excerpt($post): trim(mb_substr(strip_tags($post->post_content), 0, 70)),
));

global $post;

$thumbnail = get_post_thumbnail_id($post);

$image = array(get_template_directory_uri() . '/img/no-image.png', 600, 270);

if (!empty($thumbnail)) {

if ($image_src = wp_get_attachment_image_src($thumbnail, 'full')) {

$image = $image_src;

}

$logo = array("http://debug-life.net/logo.png", 600, 60);

echo json_encode(array(

'@context' => 'http://schema.org',

'@type' => 'NewsArticle',

'mainEntityOfPage' => array(

'@type' => 'WebPage',

'@id' => get_the_permalink($post),

'headline' => get_the_title($post),

'image' => array(

'@type' => 'ImageObject',

'url' => $image[0],

'width' => $image[1],

'height' => $image[2],

'datePublished' => get_the_date(DATE_ISO8601, $post),

'dateModified' => get_post_modified_time(DATE_ISO8601, $post),

'author' => array(

'type' => 'Person',

'name' => get_the_author_meta('nickname', $post->post_author),

'publisher' => array(

'@type' => 'Organization',

'name' => get_bloginfo('name', 'display'),

'logo' => array(

'@type' => 'ImageObject',

'url' => $logo[0],

'width' => $logo[1],

'height' => $logo[2],

)

'description' => ($post->post_excerpt && strlen($post->post_excerpt) > 0) ?

get_the_excerpt($post): trim(mb_substr(strip_tags($post->post_content), 0, 70)),

));

<div itemscope itemtype="http://schema.org/NewsArticle">
<meta itemscope itemprop="mainEntityOfPage" itemType="https://schema.org/WebPage" itemid="http://debug-life.net/entry/379"/>
<h2 itemprop="headline">Mark up articles with structured data</h2>
<h3 itemprop="author" itemscope itemtype="https://schema.org/Person">
By <span itemprop="name">debuglife</span>
</h3>
<span itemprop="description">最近Wordpressのテーマを久しぶりに書いてみたのですが、Googleウェブマスターツールで構造化データのErrorやWarningが検出されてしまいました</span>
<div itemprop="image" itemscope itemtype="https://schema.org/ImageObject">
<img src="http://debug-life.net/wp-content/uploads/2016/06/HTML5_sticker.png"/>
<meta itemprop="url" content="http://debug-life.net/wp-content/uploads/2016/06/HTML5_sticker.png">
<meta itemprop="width" content="1800">
<meta itemprop="height" content="900">
</div>
<div itemprop="publisher" itemscope itemtype="https://schema.org/Organization">
<div itemprop="logo" itemscope itemtype="https://schema.org/ImageObject">
<img src="http://debug-life.net/wp-content/uploads/2016/05/debuglife.png"/>
<meta itemprop="url" content="http://debug-life.net/wp-content/uploads/2016/05/debuglife.png">
<meta itemprop="width" content="600">
<meta itemprop="height" content="60">
</div>
<meta itemprop="name" content="DebugLife">
</div>
<meta itemprop="datePublished" content="2016-06-09T08:00:00+08:00"/>
<meta itemprop="dateModified" content="2016-06-10T09:20:00+08:00"/>
</div>

<h2 itemprop="headline">Mark up articles with structured data</h2>

By <span itemprop="name">debuglife</span>

</h3>

<span itemprop="description">最近Wordpressのテーマを久しぶりに書いてみたのですが、Googleウェブマスターツールで構造化データのErrorやWarningが検出されてしまいました</span>

</div>

</div>

</div>

</div>

WordPress Sample of Microdata

<?php
global $post;
$thumbnail = get_post_thumbnail_id($post);
$image = wp_get_attachment_image_src($thumbnail, 'full');
$logo = array("http://debug-life.net/logo.png", 600, 60);
?>
<div itemscope itemtype="http://schema.org/NewsArticle">
<meta itemscope itemprop="mainEntityOfPage"  itemType="https://schema.org/WebPage" itemid="<?php the_permalink($post) ?>"/>
<h2 itemprop="headline"><?php echo esc_html(get_the_title($post)) ?></h2>
<h3 itemprop="author" itemscope itemtype="https://schema.org/Person">
By <span itemprop="name"><?php the_author() ?></span>
</h3>
<span itemprop="description"><?php the_excerpt() ?></span>
<div itemprop="image" itemscope itemtype="https://schema.org/ImageObject">
<img src="<?php echo esc_url($image[0]) ?>"/>
<meta itemprop="url" content="<?php echo esc_url($image[0]) ?>">
<meta itemprop="width" content="<?php echo $image[1] ?>">
<meta itemprop="height" content="<?php echo $image[2] ?>">
</div>
<div itemprop="publisher" itemscope itemtype="https://schema.org/Organization">
<div itemprop="logo" itemscope itemtype="https://schema.org/ImageObject">
<img src="<?php echo esc_url($logo[0]) ?>"/>
<meta itemprop="url" content="<?php echo esc_url($logo[0]) ?>">
<meta itemprop="width" content="<?php echo $logo[1] ?>">
<meta itemprop="height" content="<?php echo $logo[2] ?>">
</div>
<meta itemprop="name" content="<?php bloginfo('name', 'display') ?>">
</div>
<meta itemprop="datePublished" content="<?php echo get_the_date(DATE_ISO8601, $post) ?>"/>
<meta itemprop="dateModified" content="<?php echo get_post_modified_time(DATE_ISO8601, $post) ?>"/>
</div>

<?php

global $post;

$thumbnail = get_post_thumbnail_id($post);

$image = wp_get_attachment_image_src($thumbnail, 'full');

$logo = array("http://debug-life.net/logo.png", 600, 60);

By <span itemprop="name"><?php the_author() ?></span>

</h3>

</div>

</div>

</div>

</div>

参考資料

https://developers.google.com/search/docs/data-types/articles

参考リンク

https://schema.org/
https://developers.google.com/search/docs/data-types/data-type-selector
